四路2输入正与非门 QUADRUPLE 2-INPUT POSITIVE-NAND GATES
description/ordering information
The ‘ACT00 devices contain four independent 2-input NAND gates. Each gate performs the Boolean function of Y = A • B or Y = A + B in positive logic.
• 4.5-V to 5.5-V VCC Operation
• Inputs Accept Voltages to 5.5 V
• Max tpd of 8 ns at 5 V
• Inputs Are TTL-Voltage Compatible
得捷:
NAND GATE, ACT SERIES
立创商城:
SN74ACT00PWLE
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74ACT00PWLE TI 德州仪器 | 当前型号 | 当前型号 |
SN74ACT00PWR 德州仪器 | 完全替代 | SN74ACT00PWLE和SN74ACT00PWR的区别 |
74ACT00MTCX 飞兆/仙童 | 功能相似 | SN74ACT00PWLE和74ACT00MTCX的区别 |
TC74ACT00FT 东芝 | 功能相似 | SN74ACT00PWLE和TC74ACT00FT的区别 |
