SN74AHCT574NE4

八路边沿触发D型触发器具有​​三态输出 OCTAL EDGE-TRIGGERED D-TYPE FLIP-FLOPS WITH 3-STATE OUTPUTS

Description

The SNx4AHCT574 devices are octal edge-triggered D-type flip-flops that feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads.

Features

• Inputs are TTL-Voltage Compatible

• Latch-Up Performance Exceeds 250 mA Per JESD 17

• On Products Compliant to MIL-PRF-38535, All Parameters are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.

• ESD Protection Exceeds JESD 22

   – 2000-V Human-Body Model A114-A

   – 200-V Machine Model A115-A

   – 1000-V Charged-Device Model C101

Applications

• Smartphone Handsets

• PDAs

• Network Switches

• Wearable Health and Fitness Devices

• Televisions LCDs

• Power Infrastructures
