八路缓冲器/驱动器，具有三态输出 OCTAL BUFFERS/DRIVERS WITH 3-STATE OUTPUTS
description/ordering information
The ’AHC541 octal buffers/drivers are ideal for driving bus lines or buffer memory address registers. These devices feature inputs and outputs on opposite sides of the package to facilitate printed circuit board layout.
Operating Range 2-V to 5.5-V VCC
Latch-Up Performance Exceeds 250 mA Per JESD 17
艾睿:
Buffer/Line Driver 8-CH Non-Inverting 3-ST CMOS 20-Pin SSOP T/R
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
SN74AHC541DBRE4 TI 德州仪器 | 当前型号 | 当前型号 |
SN74AHC541DBRG4 德州仪器 | 完全替代 | SN74AHC541DBRE4和SN74AHC541DBRG4的区别 |
SN74AHC541DBR 德州仪器 | 完全替代 | SN74AHC541DBRE4和SN74AHC541DBR的区别 |
SN74AHC541DGVR 德州仪器 | 完全替代 | SN74AHC541DBRE4和SN74AHC541DGVR的区别 |
