SN74LV02ADGVRG4

四路2输入正或非门 QUADRUPLE 2-INPUT POSITIVE-NOR GATES

description

The ’LV02A devices are quadruple 2-input positive-NOR gates designed for 2-V to 5.5-V VCC operation.

2-V to 5.5-V VCC Operation

Max tpd of 6.5ns at 5V

Typical VOLPOutput Ground Bounce

   <0.8 V at VCC = 3.3 V, TA= 25°C

Typical VOHVOutput VOH Undershoot

   >2.3 V at VCC = 3.3 V, TA= 25°C

Support Mixed-Mode Voltage Operation on All Ports

Ioff Supports Partial-Power-Down Mode Operation

贸泽:
逻辑门 Quad 2 Input Pos Nor Gates
