SMBJ7.0A-13-F

SMBJ7.0A-13-F 编带

12V 夹子 50A Ipp TVS - 表面贴装型 SMB

立创商城:
单向 Vrwm:7V 600W

得捷:
TVS DIODE 7VWM 12VC SMB

艾睿:
Protect vulnerable electronic circuits against overvoltages by equipping your device with this SMBJ7.0A-13-F TVS diode from Diodes Zetex. Its maximum leakage current is 200 μA. Its peak pulse power dissipation is 600 W. Its test current is 10 mA. This device&s;s maximum clamping voltage is 12 V and minimum breakdown voltage is 7.78 V. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment.

安富利:
Diode TVS Single Uni-Dir 7V 600W 2-Pin SMB T/R

Chip1Stop:
Diode TVS Single Uni-Dir 7V 600W 2-Pin SMB T/R

Verical:
Diode TVS Single Uni-Dir 7V 600W 2-Pin SMB T/R
