S3KB 系列 800 V 3 A 表面贴装 玻璃钝化 整流器 - DO-214AA
标准 800 V 3A 表面贴装型 SMB
得捷:
DIODE GEN PURP 800V 3A SMB
立创商城:
800V 3A 1.15V@3A
艾睿:
Converting from AC to DC is simple when using a switching diode S3KB-13-F rectifier from Diodes Zetex. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its peak non-repetitive surge current is 100 A, while its maximum continuous forward current is 3 A. This rectifier has a minimum operating temperature of -65 °C and a maximum of 150 °C. It is made in a single configuration.
Allied Electronics:
Diode Switching 800V 3A 2Pin SMB
安富利:
Diode Switching 800V 3A 2-Pin SMB T/R
Chip1Stop:
Diode Switching 800V 3A 2-Pin SMB T/R
Verical:
Diode Switching 800V 3A Automotive 2-Pin SMB T/R
儒卓力:
**SI-DIODE 3A 800V SMB **
Win Source:
DIODE GEN PURP 800V 3A SMB
额定电压DC 800 V
额定电流 3.00 A
电容 40.0 pF
输出电流 ≤3.00 A
正向电压 1.15V @3A
极性 Standard
热阻 10℃/W RθJL
正向电流 3000 mA
正向电压Max 1.15V @3A
正向电流Max 3 A
工作温度Max 150 ℃
工作温度Min -65 ℃
安装方式 Surface Mount
引脚数 2
封装 SMB
封装 SMB
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
S3KB-13-F Diodes 美台 | 当前型号 | 当前型号 |
S3KB-13 美台 | 完全替代 | S3KB-13-F和S3KB-13的区别 |
MURS105T3G 安森美 | 功能相似 | S3KB-13-F和MURS105T3G的区别 |
MURS230T3G 安森美 | 功能相似 | S3KB-13-F和MURS230T3G的区别 |
