ESD 抑制器/TVS 二极管
ESD 抑制器/TVS
得捷:
TVS DIODE 13VWM 21.5VC SMB
立创商城:
单向 Vrwm:13V 600W
贸泽:
TVS Diodes - Transient Voltage Suppressors 600W 13.0V
艾睿:
Prevent your circuits from experiencing malfunctions from electrostatic discharge with this SMBJ13A-13-F TVS diode from Diodes Zetex. Its maximum leakage current is 5 μA. Its test current is 1 mA. This device&s;s maximum clamping voltage is 21.5 V and minimum breakdown voltage is 14.4 V. Its peak pulse power dissipation is 600 W. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.
安富利:
Diode TVS Single Uni-Dir 13V 600W 2-Pin SMB T/R
Chip1Stop:
Diode TVS Single Uni-Dir 13V 600W 2-Pin SMB T/R
Verical:
Diode TVS Single Uni-Dir 13V 600W 2-Pin SMB T/R
儒卓力:
**TRANSIL UNI 0,6KW 15V SMB **
Win Source:
TVS DIODE 13VWM 21.5VC SMB
额定电压DC 13.0 V
额定功率 600 W
击穿电压 16.5 V
电路数 1
耗散功率 600 W
钳位电压 21.5 V
最大反向电压(Vrrm) 13V
测试电流 1 mA
脉冲峰值功率 600 W
最小反向击穿电压 14.4 V
击穿电压 14.4 V
工作温度Max 150 ℃
工作温度Min 55 ℃
工作结温 -55℃ ~ 150℃
安装方式 Surface Mount
引脚数 2
封装 SMB
长度 4.57 mm
宽度 3.9 mm
高度 2.62 mm
封装 SMB
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SMBJ13A-13-F Diodes 美台 | 当前型号 | 当前型号 |
SMBJ13A-E3/52 威世 | 类似代替 | SMBJ13A-13-F和SMBJ13A-E3/52的区别 |
1SMB13AT3G 安森美 | 功能相似 | SMBJ13A-13-F和1SMB13AT3G的区别 |
SMBJ13 力特 | 功能相似 | SMBJ13A-13-F和SMBJ13的区别 |
