ESD 抑制器/TVS 二极管
ESD 抑制器/TVS
得捷:
TVS DIODE 12VWM 19.9VC SMB
立创商城:
双向 Vrwm:12V
贸泽:
ESD 抑制器/TVS 二极管 600W 12.0V
e络盟:
TVS二极管, SMBJ Series, 双向, 12 V, 19.9 V, DO-214AA, 2 引脚
艾睿:
Surges can be a costly problem, avoid the pain and suffering by implementing this SMBJ12CA-13-F TVS diode from Diodes Zetex. This device&s;s maximum clamping voltage is 19.9 V and minimum breakdown voltage is 13.3 V. Its peak pulse power dissipation is 600 W. Its test current is 1 mA. Its maximum leakage current is 5 μA. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 150 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components.
安富利:
Diode TVS Single Bi-Dir 12V 600W 2-Pin SMB T/R
Chip1Stop:
Diode TVS Single Bi-Dir 12V 600W 2-Pin SMB T/R
Verical:
Diode TVS Single Bi-Dir 12V 600W 2-Pin SMB T/R
儒卓力:
**TRANSIL BI 0,6KW 14V SMB **
Win Source:
TVS DIODE 12VWM 19.9VC SMB
额定电压DC 12.0 V
工作电压 12 V
电容 340 pF
额定功率 600 W
击穿电压 13.3 V
电路数 1
针脚数 2
耗散功率 600 W
钳位电压 19.9 V
测试电流 1 mA
最大反向击穿电压 15.3 V
脉冲峰值功率 600 W
最小反向击穿电压 13.3 V
击穿电压 13.3 V
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温 -55℃ ~ 150℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AA-2
长度 4.57 mm
宽度 3.9 mm
高度 2.62 mm
封装 DO-214AA-2
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
SMBJ12CA-13-F Diodes 美台 | 当前型号 | 当前型号 |
SMBJ12CA-13 美台 | 完全替代 | SMBJ12CA-13-F和SMBJ12CA-13的区别 |
1SMB12CAT3G 安森美 | 功能相似 | SMBJ12CA-13-F和1SMB12CAT3G的区别 |
SMBJ12CA 伯恩斯 | 功能相似 | SMBJ12CA-13-F和SMBJ12CA的区别 |
