TMS32C6713BZDPA200

TEXAS INSTRUMENTS  TMS32C6713BZDPA200  芯片, 数字信号处理器, 32位, 200MHZ, BGA-272

* Highest-Performance Floating-Point Digital Signal Processor DSP: TMS320C6713B * Eight 32-Bit Instructions/Cycle * 32/64-Bit Data Word * 300-, 225-, 200-MHz GDP and ZDP, and 225-, 200-, 167-MHz PYP Clock Rates * 3.3-, 4.4-, 5-, 6-Instruction Cycle Times * 2400/1800, 1800/1350, 1600/1200, and 1336/1000 MIPS/MFLOPS * Rich Peripheral Set, Optimized for Audio * Highly Optimized C/C++ Compiler * Extended Temperature Devices Available * Advanced Very Long Instruction Word VLIW TMS320C67x™ DSP Core * Eight Independent Functional Units: * 2 ALUs Fixed-Point * 4 ALUs Floating-/Fixed-Point * 2 Multipliers Floating-/Fixed-Point * Load-Store Architecture With 32 32-Bit General-Purpose Registers * Instruction Packing Reduces Code Size * All Instructions Conditional * Instruction Set Features * Native Instructions for IEEE 754 * Single- and Double-Precision * Byte-Addressable 8-, 16-, 32-Bit Data * 8-Bit Overflow Protection * Saturation; Bit-Field Extract, Set, Clear; Bit-Counting; Normalization * L1/L2 Memory Architecture * 4K-Byte L1P Program Cache Direct-Mapped * 4K-Byte L1D Data Cache 2-Way * 256K-Byte L2 Memory Total: 64K-Byte L2 Unified Cache/Mapped RAM, and 192K-Byte Additional L2 Mapped RAM * Device Configuration * Boot Mode: HPI, 8-, 16-, 32-Bit ROM Boot * Endianness: Little Endian, Big Endian * 32-Bit External Memory Interface EMIF * Glueless Interface to SRAM, EPROM, Flash, SBSRAM, and SDRAM * 512M-Byte Total Addressable External Memory Space * Enhanced Direct-Memory-Access EDMA Controller 16 Independent Channels * 16-Bit Host-Port Interface HPI * Two McASPs * Two Independent Clock Zones Each 1 TX and 1 RX * Eight Serial Data Pins Per Port: Individually Assignable to any of the Clock Zones * Each Clock Zone Includes: * Programmable Clock Generator * Programmable Frame Sync Generator * TDM Streams From 2-32 Time Slots * Support for Slot Size: 8, 12, 16, 20, 24, 28, 32 Bits * Data Formatter for Bit Manipulation * Wide Variety of I2S and Similar Bit Stream Formats * Integrated Digital Audio Interface Transmitter DIT Supports: * S/PDIF, IEC60958-1, AES-3, CP-430 Formats * Up to 16 transmit pins * Enhanced Channel Status/User Data * Extensive Error Checking and Recovery * Two Inter-Integrated Circuit Bus I2C Bus™ Multi-Master and Slave Interfaces * Two Multichannel Buffered Serial Ports: * Serial-Peripheral-Interface SPI * High-Speed TDM Interface * AC97 Interface * Two 32-Bit General-Purpose Timers * Dedicated GPIO Module With 16 pins External Interrupt Capable * Flexible Phase-Locked-Loop PLL Based Clock Generator Module * IEEE-1149.1 JTAG Boundary-Scan-Compatible * 208-Pin PowerPAD™ PQFP PYP * 272-BGA Packages GDP and ZDP * 0.13-µm/6-Level Copper Metal Process * CMOS Technology * 3.3-V I/Os, 1.2-V Internal GDP/ZDP/ PYP * 3.3-V I/Os, 1.4-V Internal GDP/ZDP [300 MHz]
