DSP控制器 DSP CONTROLLERS
The digital signal processor from Texas Instruments is wonderful for converting signals fast! This DSP processor has an operating temperature range of -40 °C to 85 °C. 40 MHz is its maximum speed. This device is based on the C2xx core architecture. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3|4.75 V, while its maximum is 3.6|5.25 V. Its flash program memory is 16KB. This is a 16 bit processor. Its ADC resolution is 10 Bit.
频率 40.0 MHz
电源电压DC 3.00V min
时钟频率 40.0 MHz
RAM大小 2K x 8
FLASH内存容量 16 KB
I/O引脚数 13
UART数量 1
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Max 3.6 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 32
封装 LQFP-32
封装 LQFP-32
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Not Recommended for New Designs
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 3A991.a.2
香港进出口证 NLR
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TMS320LF2401AVFA TI 德州仪器 | 当前型号 | 当前型号 |
TMS320LF2401AVFS 德州仪器 | 类似代替 | TMS320LF2401AVFA和TMS320LF2401AVFS的区别 |
