TEXAS INSTRUMENTS TMS320DM8168ACYG2 芯片, 数字信号处理器, DAVANCI系列, 1031-FCBGA
Never worry about data not properly being processed by using this application processor from Texas Instruments it will centralize your processing needs. This part has an operating temperature range of 0 °C to 95 °C. It has a maximum clock speed of 1100 MHz. This device utilizes 0.04um technology. It has romless program memory. Its Ethernet interface type is mii and supports up to 10Mbps/100Mbps/1000Mbps. This device is based on the ARM Cortex A8 core architecture. This device has a minimum operating supply voltage of 0.8 V and a maximum of 1.05 V.
频率 1.00 GHz
电源电压DC 3.13V min
针脚数 1031
时钟频率 1.00 GHz
RAM大小 64 KB
UART数量 3
工作温度Max 95 ℃
工作温度Min 0 ℃
电源电压Max 3.47 V
电源电压Min 3.13 V
安装方式 Surface Mount
引脚数 1031
封装 FCBGA-1031
高度 2.81 mm
封装 FCBGA-1031
工作温度 0℃ ~ 95℃ TJ
产品生命周期 Obsolete
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 5A002
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TMS320DM8168ACYG2 TI 德州仪器 | 当前型号 | 当前型号 |
TMS320DM8168SCYG2 德州仪器 | 完全替代 | TMS320DM8168ACYG2和TMS320DM8168SCYG2的区别 |
TMS320DM8168CCYG2 德州仪器 | 类似代替 | TMS320DM8168ACYG2和TMS320DM8168CCYG2的区别 |
