TEXAS INSTRUMENTS TS5A22366YFCR 模拟开关, SPDT, 2 放大器, 1.8 ohm, 2.25V 至 5.5V, DSBGA, 12 引脚
The TS5A22366 is a dual single-pole double-throw SPDT analog switch that is designed to operate from 2.25 V to 5.5 V. The device features negative signal capability that allows signals below ground to pass through the switch without distortion.
The break-before-make feature prevents signal distortion during the transferring of a signal from one path to another. Low ON-state resistance, excellent channel-to-channel ON-state resistance matching, and minimal total harmonic distortion THD performance are ideal for audio applications.
The TS5A22366 is available is a ultra small 1.6 mm × 1.2 mm wafer-chip-scale package WCSP 0.4 mm pitch.
电源电压DC 2.25V ~ 5.50V
输出接口数 2
供电电流 6 µA
电路数 2
通道数 2
针脚数 12
电压波节 2.50 V, 3.00 V, 3.30 V, 5.00 V
带宽 32 MHz
输入数 4
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 32 MHz
电源电压 2.25V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.25 V
安装方式 Surface Mount
引脚数 12
封装 DSBGA-12
封装 DSBGA-12
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
