TPSA475K020R1800

AVX  TPSA475K020R1800  表面贴装钽电容, TPS系列, 4.7 µF, ± 10%, 20 V, 1206 [3216 公制], A

钽器

欧时:
### TPS 系列 20 至 50V 直流AVX 的 TPS 系列低 ESR 贴片式电容器，设计主要用于电源应用。 TPS 系列电容器提供 14 种不同的外壳尺寸。低 ESR（等效串联电阻） 高波纹电流能力 低功率和热消散 尺寸 mm ---   | L | W | H | W1 | A 外壳代码 | +-0.2 | +-0.2 | +-0.2 | +-0.2 | +-0.3-0.2 A | 3.2 | 1.6 | 1.6 | 1.2 | 0.8 B | 3.5 | 2.8 | 1.9 | 2.2 | 0.8 C | 6 | 3.2 | 2.6 | 2.2 | 1.3 D | 7.3 | 4.3 | 2.9 | 2.4 | 1.3 E | 7.3 | 4.3 | 4.1 | 2.4 | 1.3 V | 7.3 | 6.1 | 3.45 | 3.1 | 1.4 W | 6 | 3.2 | 1.5 | 2.2 | 1.3 ![http://china.rs-online.com/largeimages/L405941-01.gif]http://china.rs-online.com/largeimages/L405941-01.gif ### SMT 125°C

e络盟:
表面贴装钽电容, 4.7 µF, 20 V, 1206 [3216 公制], TPS系列, ± 10%, -55 °C

艾睿:
This TPSA475K020R1800 solid tantalum capacitor from AVX will retain its properties through a variety of operating conditions. It can withstand a voltage of 20 VDC. This solid capacitor has a maximum operating temperature of 125 °C. Its leakage current is 0.9 μA. This product is 3.2 mm long, 1.6 mm tall and 1.6 mm deep. Its capacitance value is 4.7uF. It has a tolerance of 10%.

Allied Electronics:
Capacitor; Tantalum; Cap 4.7 uF; Tol 10%; SMT; Vol-Rtg 20V; Low ESR; Cut Tape

安富利:
Cap Tant Solid 4.7uF 20V A CASE 10% 3.2 X 1.6 X 1.6mm SMD 3216-18 1.8 Ohm 125°C T/R

富昌:
TPS 系列 4.7 uF ±10 % 20 V 表面贴装 低ESR 钽 贴片电容

Chip1Stop:
Cap Tant Solid 4.7uF 20V A CASE 10% 3.2 X 1.6 X 1.6mm SMD 3216-18 1.8 Ohm 125A？A℃ T/R

TME:
Capacitor: tantalum; low ESR; 4.7uF; 20VDC; Case: A; 1206; TPS; SMD

Verical:
Cap Tant Solid 4.7uF 20V A CASE 10% 3.2 X 1.6 X 1.6mm Inward L SMD 3216-18 1.8 Ohm 125C T/R

Newark:
# AVX  TPSA475K020R1800  Surface Mount Tantalum Capacitor, 4.7 µF, 20 V, TPS Series, ± 10%, 1206 [3216 Metric]

儒卓力:
**TC 4,7uF 20V 10% CaseA 1800mOhm **
