TPS730285DBVT

TEXAS INSTRUMENTS  TPS730285DBVT  固定电压稳压器, LDO, 2.7V至5.5V, 120mV压差, 2.85V输出, 200mA输出, SOT-23-5

The is a 2.85V fixed output low-power low-dropout LDO Linear Regulator features high power-supply rejection ratio PSRR, low noise, fast start-up and excellent line and load transient responses. The device is stable with a small 2.2µF ceramic capacitor on the output. The device family uses an advanced, proprietary BiCMOS fabrication process to yield low-dropout LDO voltages. The device achieves fast start-up times approximately 50µs with a 0.001µF bypass capacitor while consuming low quiescent current 170µA typical. Moreover, when the device is placed in standby mode, the supply current is reduced to less than 1µA.

.

68dB at 100Hz High PSRR

.

50µs Fast start-up time

.

Stable with a 2.2µF ceramic capacitor

.

Excellent load/line transient response

.

Green product and no Sb/Br
