TEXAS INSTRUMENTS TPS54426PWP.. 芯片, 直流/直流降压转换器, 700KHz, HTSSOP-14
降压 开关稳压器 IC 正 可调式 0.76V 1 输出 4A 14-PowerTSSOP(0.173",4.40mm 宽)
得捷:
IC REG BUCK ADJ 4A 14HTSSOP
立创商城:
降压型 Vin=4.5V~18V Vout=760mV~5.5V 4A
德州仪器TI:
4.5V to 18V Input, 4A Synchronous Step-Down Converter with Eco-Mode™
贸泽:
开关稳压器 4.5-18V Inp,4A Synch SWIFT Converter
e络盟:
TEXAS INSTRUMENTS TPS54426PWP 直流-直流开关降压逐步递减稳压器, 可调, 4.5V-18V输入, 760mV-5.5V输出, 4A输出, HTSSOP-14
艾睿:
Adjust the voltage level of your devices with this step down TPS54426PWP DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 4 A. It only needs a voltage of at least 4.5 V while not exceeding 18 V to effectively power your circuit. With an adjustable output that has a voltage of 0.76 to 5.5 V, this is power management at its best. At a load regulation of 100mV and line regulation of 20mV your circuit is capable of maintaining a constant voltage level at your output. This part offers a switching frequency of 700Typ kHz in order to work properly. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 4.5V to 18V 14-Pin HTSSOP EP Tube
Verical:
Conv DC-DC 4.5V to 18V Step Down Single-Out 0.76V to 5.5V 4A 14-Pin HTSSOP EP Tube
Newark:
# TEXAS INSTRUMENTS TPS54426PWP DC-DC Switching Buck Step Down Regulator, Adjustable, 4.5V-18Vin, 760mV-5.5Vout, 4Aout, HTSSOP-14
DeviceMart:
IC REG BUCK SYNC ADJ 4A 14HTSSOP
Win Source:
Buck Switching Regulator IC Positive Adjustable 0.76V 1 Output 4A 14-TSSOP 0.173", 4.40mm Width Exposed Pad
输出接口数 1
输出电压 0.76V ~ 5.5V
输出电流 4 A
针脚数 14
静态电流 850 µA
调节输出数 1
开关频率 700 kHz
拓扑结构 Buck
输入电压Max 18 V
输入电压Min 4.5 V
输出电压Max 5.5 V
输出电压Min 760 mV
输出电流Max 4 A
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 4.5V ~ 18V
安装方式 Surface Mount
引脚数 14
封装 HTSSOP-14
封装 HTSSOP-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS54426PWP TI 德州仪器 | 当前型号 | 当前型号 |
TPS54426PWPR 德州仪器 | 类似代替 | TPS54426PWP和TPS54426PWPR的区别 |
