TEXAS INSTRUMENTS TPS40041DRBR 直流/直流控制器, 2.25V至5.5V, 1路输出, 同步降压, 700kHz, SON-8
降压 稳压器 正 输出 降压 - DC DC 切换控制器 IC 8-SON(3x3)
得捷:
IC REG CTRLR BUCK 8SON
立创商城:
TPS40041DRBR
德州仪器TI:
2.25 to 5.5 V input, 600 kHz, synchronous buck controller with low pin count
e络盟:
直流/直流控制器, 2.25V至5.5V, 1路输出, 同步降压, 700kHz, SON-8
艾睿:
Many components require different DC voltage levels to operate properly. The synchronous buck TPS40041DRBR DC voltage controller from Texas Instruments can safely provide the proper level. Its output produces a current of 15Max A. This DC voltage controller has single output. With an output that has a voltage of 0.6 to 4.95 V, this is power management at its best. This DC voltage controller has an input voltage of 2.25 to 5.5 V. You can operate this at a switching frequency of 700 kHz. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This DC voltage controller has an operating temperature range of -40 °C to 125 °C.
安富利:
DC DC Cntrlr Single-OUT Sync Buck 2.25V to 5.5V Input 8-Pin VSON EP T/R
Chip1Stop:
DC/DC Controller External Switch Low Pin Count, Low Vin Synchronous Buck DC/DC Controller DC DC Cntrlr Single-OUT Sync Step Down 2.25V to 5.5V Input 8-Pin VSON EP T/R
Verical:
DC DC Cntrlr Single-OUT Sync Buck 2.25V to 5.5V Input 8-Pin VSON EP T/R
Newark:
# TEXAS INSTRUMENTS TPS40041DRBR DC/DC Controller, 2.25V to 5.5V, 1 Output, Synchronous Buck, 700kHz, SON-8
Win Source:
Buck Regulator Positive Output Step-Down DC-DC Controller IC 8-SON Exposed Pad 3x3
DeviceMart:
IC REG CTRLR BUCK PWM VM 8-SON
电源电压DC 2.25V min
输出接口数 1
输出电压 0.6V ~ 4.95V
输出电流 15 A
针脚数 8
耗散功率 2000 mW
静态电流 2.00 mA
调节输出数 1
开关频率 700 kHz
过温保护 Yes
拓扑结构 Buck
占空比 95 %
输入电压Max 5.5 V
输入电压Min 2.25 V
输出电流Max 15 A
最大占空比 0.95
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 2000 mW
电源电压 2.25V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.25 V
输入电压 2.25V ~ 5.5V
安装方式 Surface Mount
引脚数 8
封装 VSON EP-8
封装 VSON EP-8
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通信与网络, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS40041DRBR TI 德州仪器 | 当前型号 | 当前型号 |
TPS40041DRBT 德州仪器 | 类似代替 | TPS40041DRBR和TPS40041DRBT的区别 |
TPS40041DRBTG4 德州仪器 | 类似代替 | TPS40041DRBR和TPS40041DRBTG4的区别 |
TPS40041DRBRG4 德州仪器 | 类似代替 | TPS40041DRBR和TPS40041DRBRG4的区别 |
