TEXAS INSTRUMENTS TLV3491AIDBVTG4 模拟比较器, 轨至轨, 纳功率, 1, 6 µs, 1.8V 至 5.5V, SOT-23, 5 引脚
通用 CMOS,推挽式,满摆幅 SOT-23-5
得捷:
IC COMPARATOR 1 GEN PUR SOT23-5
立创商城:
TLV3491AIDBVTG4
贸泽:
模拟比较器 Single Nanopower Push-Pull Output
e络盟:
模拟比较器, 轨至轨, 纳功率, 1个比较器, 6 µs, 1.8V 至 5.5V, SOT-23, 5 引脚
艾睿:
Comparator Single R-R I/O 5.5V 5-Pin SOT-23 T/R
安富利:
The TLV349x family of push-pull output comparators features a fast 6µs response time, and Micro-sized packages provide options for portable and space-restricted applications. The single TLV3491 is available in SOT23-5, and SO-8. The dual TLV3492 comes in SOT23-8, and SO-8. The quad TLV3494 is available in TSSOP-14, and SO-14.The TLV349x is excellent for power-sensitive, low-voltage 2-cell applications.
Chip1Stop:
Comparator Single R-R I/O 5.5V 5-Pin SOT-23 T/R
Verical:
Comparator Single R-R I/O 5.5V 5-Pin SOT-23 T/R
Newark:
# TEXAS INSTRUMENTS TLV3491AIDBVTG4 Analogue Comparator, Rail to Rail, Nanopower, 1, 6 s, 1.8V to 5.5V, SOT-23, 5
电源电压DC 1.80V min
输出电流 5.00 mA
供电电流 580 nA
电路数 1
通道数 1
针脚数 5
共模抑制比 74 dB
输入补偿电压 15 mV
输入偏置电流 0.01 nA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.8V ~ 5.5V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 无线, 传感与仪器, 安全, 医用, 便携式器材
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV3491AIDBVTG4 TI 德州仪器 | 当前型号 | 当前型号 |
TLV3491AIDBVR 德州仪器 | 完全替代 | TLV3491AIDBVTG4和TLV3491AIDBVR的区别 |
TLV3491AIDBVT 德州仪器 | 完全替代 | TLV3491AIDBVTG4和TLV3491AIDBVT的区别 |
