TAJB227M004RNJ

AVX  TAJB227M004RNJ  表面贴装钽电容, TAJ系列, 220 µF, ± 20%, 4 V, 1210 [3225 公制], B

钽器

欧时:
### TAJ 标准系列 2.5 至 16V 直流TAJ 系列为通用表面安装片式钽电容器 提供 7 种外壳尺寸 提供薄型选件 CV 范围：0.10-2200μF / 2.5-50V 应用包括：通用低功率直流/直流和低压降调节器 技术参数 --- 温度范围 °C | \- 55 至 +85 电容 % | 10 尺寸 mm --- 外壳代码 | L | W | H | W1 | A 容差 | ±0.2 | +0.2/–0.1 | +0.2/–0.1 | +0.2 | +0.3/–0.2 A | 3.2 | 1.6 | 1.6 | 1.2 | 0.8 B | 3.5 | 2.8 | 1.9 | 2.2 | 0.8 C | 6.0 | 3.2 | 2.6 | 2.2 | 1.3 D | 7.3 | 4.3 | 2.9 | 2.4 | 1.3 E | 7.3 | 4.3 | 4.1 | 2.4 | 1.3 ![http://china.rs-online.com/largeimages/L405941-01.gif]http://china.rs-online.com/largeimages/L405941-01.gif ### 表面安装 85 ° C

立创商城:
220uF ±20% 4V

贸泽:
钽质电容器-固体SMD 4V 220uF 20% 1210 ESR= 1.1 Ohms

艾睿:
If you need a capacitor that can be used in a variety of applications such as heavy industrial, medical, military, and aerospace then use this TAJB227M004RNJ solid tantalum capacitor from AVX. It can withstand a voltage of 4 VDC. Its leakage current is 8.8 μA. This solid capacitor has a maximum operating temperature of 125 °C. This product is 3.5 mm long, 1.9 mm tall and 2.8 mm deep. Its capacitance value is 220uF. It has a tolerance of 20%.

Allied Electronics:
220uF SMD Solid MnO2 Tantalum Electrolytic Capacitor, 4 V dc +/-20%, TAJ Series

安富利:
Cap Tant Solid 220uF 4V B CASE 20% 3.5 X 2.8 X 1.9mm SMD 3528-21 1.1 Ohm 125°C T/R

TME:
Capacitor: tantalum; 220uF; 4VDC; SMD; Case: B; 1210; ±20%; -55÷125°C

Verical:
Cap Tant Solid 220uF 4V B CASE 20% 3.5 X 2.8 X 1.9mm Inward L SMD 3528-21 1.1 Ohm 125C T/R

Newark:
# AVX  TAJB227M004RNJ  Surface Mount Tantalum Capacitor, 220 µF, 4 V, TAJ Series, ± 20%, 1210 [3225 Metric]

儒卓力:
**TC 220uF 4,0V 20% Case B **

Win Source:
CAP TANT 220UF 4V 20% 1210
