Texas Instruments
功率多路复用器,Texas Instruments
### 负载开关 IC,Texas Instruments
得捷:
IC OR CTRLR SRC SELECT 8TSSOP
立创商城:
TPS2111PW
德州仪器TI:
2.8-V to 5.5-V, 84-mΩ, 1.25-A, power mux with manual, automatic and slow switchover
欧时:
Texas Instruments TPS2111PW 2输入/1输出 功率 Mux, 自动切换, 1.25A最大输出, 5.5 V输入, 8引脚
艾睿:
Easily distribute power across multiple feeders using the Texas Instruments TPS2111PW power multiplexer for a better system. This power mux&s;s single output can produce a current up to 1.25 A. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This power mux has an operating temperature range of -40 °C to 85 °C.
安富利:
Pwr Mux Autoswitch 1.5V to 5.5V 1.25A 8-Pin TSSOP Tube
Chip1Stop:
Pwr Mux Autoswitch 1.5V to 5.5V 1.25A 8-Pin TSSOP Tube
Verical:
Pwr Mux Autoswitch 1.5V to 5.5V 1.25A 8-Pin TSSOP Tube
Newark:
# TEXAS INSTRUMENTS TPS2111PW Autoswitching Power Multiplexer, Dual Input, High Side, Active High, 1 Output, 5.5V, 1.25A, TSSOP-8
力源芯城:
双入/单出,电源MUX
Win Source:
IC OR CTRLR SRC SELECT 8TSSOP
DeviceMart:
IC OR CTRLR SRC SELECT 8TSSOP
电源电压DC 5.50V max
输出接口数 1
输入电压DC 5.50 V
输出电压 ≤6.00 V
输出电流 1.25 A
供电电流 55 µA
耗散功率 386.84 mW
输入电压Max 5.5 V
输入电压Min 1.5 V
输出电流Max 1.25 A
输入数 2
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 386.84 mW
电源电压 2.8V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.8 V
输入电压 1.5V ~ 5.5V
安装方式 Surface Mount
引脚数 8
封装 TSSOP-8
长度 3 mm
宽度 4.4 mm
高度 1.15 mm
封装 TSSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 手持/移动设备
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS2111PW TI 德州仪器 | 当前型号 | 当前型号 |
TPS2111PWR 德州仪器 | 完全替代 | TPS2111PW和TPS2111PWR的区别 |
TPS2111PWRG4 德州仪器 | 完全替代 | TPS2111PW和TPS2111PWRG4的区别 |
TPS2111PWG4 德州仪器 | 类似代替 | TPS2111PW和TPS2111PWG4的区别 |
