微功率电源电压监控器 Micropower Supply Voltage Supervisors
You will no longer have to worry about under or overvoltages with this supply voltage supervisory voltage monitor IC from Texas Instruments. This device has a maximum power dissipation of 725 mW. Its maximum power dissipation is 725 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a typical reset threshold voltage of 1.1 V, with a minimum of 1.04 V and a maximum of 1.16 V. This voltage supervisor IC has an operating temperature range of -40 °C to 85 °C. This device has a minimum operating supply voltage of 2 V and a maximum of 6 V.
电源电压DC 2.00V min
供电电流 9 µA
针脚数 8
耗散功率 0.725 W
静态电流 9.00 µA
阈值电压 1.1 V
复位电压Min 1.04 V
复位电压Max 1.16 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 725 mW
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TLC7701IDR TI 德州仪器 | 当前型号 | 当前型号 |
TLC7701ID 德州仪器 | 类似代替 | TLC7701IDR和TLC7701ID的区别 |
TLC7701QD 德州仪器 | 类似代替 | TLC7701IDR和TLC7701QD的区别 |
TLC7701IDG4 德州仪器 | 类似代替 | TLC7701IDR和TLC7701IDG4的区别 |
