TC164-JR-07180KL

180kΩ ±5%

The TC 164 series are thick film array chip resistors. These integrated discrete resistors can effectively reduce PCB space with high component reliability and are more efficient for pick & place application. The Resistance range includes E96 and E24 decade values from 10 ohm to 1Mohm.

.

4 × 0603 standard package

.

±1% and ±5% tolerance

.

Operating temperature range -55°C to +155°C

.

Power rating of 62.5mW

.

Maximum working voltage of 50V

.

Temperature coefficient is ±200ppm/°C

.

Low assembly cost

.

Jumpers are also available
