TC164-JR-073K3L

TC164 系列 4 元件 3.3 kohm 5 % 外壳 4 x 0603 SMD 贴片电阻网络

器网络与阵列

得捷:
RES ARRAY 4 RES 3.3K OHM 1206

立创商城:
TC164-JR-073K3L

e络盟:
固定阵列电阻, 3.3 kohm, ARC系列, 4 元件, 隔离, 1206 [3216公制], 8 引脚

艾睿:
By combining multiple resistors into a single chip, the TC164-JR-073K3L resistor array, developed by Yageo, can help you save space and power in your circuit design. This dependable part has a power rating per resistor of 0.063 1/16 W. This product&s;s 4 resistors have a value of 3.3K Ohm. Its temperature coefficient is ±200 ppm/°C. It has 8 terminals. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It has a tolerance of 5%. This product&s;s terminal pitch is 0.8 mm. The TC164-JR-073K3L part has a concave termination style. This device is made with thick film technology. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 155 °C.

Chip1Stop:
Res Thick Film Array 3.3K Ohm 5% ±200ppm/℃ ISOL Molded 8-Pin 12064 X 0603 Concave SMD Paper T/R

Verical:
Res Thick Film Array 3.3K Ohm 5% ±200ppm/C ISOL Epoxy 8-Pin 12064 X 0603 Concave SMD Automotive T/R

Newark:
# YAGEO PHYCOMP  TC164-JR-073K3L  RESISTOR ARRAY, ARC241 1206 3K3

儒卓力:
**CN1206R4 3,3K 5% 0,063W CONCAVE **
