TLP525G

TLP525G

Triac Drive

Programmable Controllers

AC−Output Module

Solid State Relay

The TOSHIBA , −2 and −4 consist of a photo−triac optically coupled to a gallium arsenide infrared emitting diode. The TLP525G−2 offers two isolated channels in an eight lead plastic DIP package, while the TLP525G−4 provides four isolated channels in a sixteen lead plastic DIP package.

•  Peak off−stage voltage: 400V min.

•  Trigger LED current: 10mA max.

•  Peak on−stage current: 2Apk max.

•  Isolation voltage: 2500Vrms min.
