THS7353PWRG4

具有 I2C 控制、可选滤波器、0dB 增益、2:1 多路复用器的 3 通道低功耗视频放大器 20-TSSOP -40 to 85

DESCRIPON

Fabricated using the new complimentary silicon germanium SiGe BiCom-III process, the THS7353 is a low-power, single-supply 2.7-V to 5-V, 3-channel integrated video buffer. It incorporates a selectable 5th order Butterworth anti-aliasing / DAC reconstruction filter to eliminate data converter images. The 9-MHz is a perfect choice for SDTV video including composite, S-Video™, and 480i/576i Y"P"BP"R or G"B"R" R"G"B" video. The 16-MHz filter is ideal for EDTV 480p/576p Y"P"BP"R, G"B"R", and VGA signals. The 35-MHz filter is useful for HDTV 720p/1080i Y"P"BP"R, G"B"R", and SVGA/XGA signals. For 1080p or SXGA/UXGA signals, the filter can be bypassed allowing a 150-MHz bandwidth, 300-V/μs amplifier to buffer the signal.

FEATURES

• 3-Video Buffers for CVBS, S-Video, SD/ED/HD Y"P"BP"R, and G"B"R" R"G"B" Video

• I2C™ Control of All Functions

• Integrated Low-Pass Filters

   – 5th Order Butterworth Characteristics

   – Selectable Corner Frequencies of 9-MHz,

16-MHz, 35-MHz, and Bypass 150-MHz

• Selectable Input Bias Modes

   – AC-Coupled with Sync-Tip Clamp

   – AC-Coupled with Bias

   – DC-Coupled with 250-mV Input Shift

   – DC-Coupled

• 2:1 Input MUX Allows Multiple Input Sources

• External Gain Control Range From 0 dB to 14 dB

• 2.7-V to 5-V Single Supply Operation

• Low 16.2-mA 3.3 V Total Quiescent Current

• Disable < 1 μA and Mute Control Functions

• Rail-to-Rail Output:

   – Allows AC or DC Output Coupling

• Low Differential Gain/Phase of 0.15%/0.3°

APPLICATIONS

• HDTV Video Buffering

• PVR/DVDR Video Buffering

• Projector Video Buffering

• USB/Portable Low Power Video Buffering
