TLV2474ID

TEXAS INSTRUMENTS  TLV2474ID  运算放大器, 四路, 2.8 MHz, 4个放大器, 1.5 V/µs, ± 1.35V 至 ± 3V, SOIC, 14 引脚

The is a quad low-power CMOS Operational Amplifier with rail-to-rail input/output. It establishes a new performance point for supply current versus AC performance. This device consumes just 600µA/channel while offering 2.8MHz of gain-bandwidth product. Along with increased AC performance, the amplifier provides high output drive capability, solving a major shortcoming of older MicroPower operational amplifier. The TLV247x can swing to within 180mV of each supply rail while driving a 10mA load. For non-RRO applications, the TLV247x can supply ±35mA at 500mV off the rail. Both the inputs and outputs swing rail-to-rail for increased dynamic range in low-voltage applications. This performance makes the TLV247x family ideal for sensor interface and other data acquisition circuits.

.

2.5pA Input bias current

.

250µV typical Input offset voltage

.

0.4µV/°C Typical offset drift

.

84dB Typical CMRR

.

Green product and no Sb/Br
