家庭2.7 -V高转换率轨至轨输出运算放大器，带有关断 FAMILY OF 2.7-V HIGH-SLEW-RATE RAIL-TO-RAIL OUTPUT OPERATIONAL AMPLIFIERS WITH SHUTDOWN
description
The TLV277x CMOS operational amplifier family combines high slew rate and bandwidth, rail-to-rail output swing, high output drive, and excellent dc precision. The device provides 10.5 V/µs of slew rate and 5.1 MHz of bandwidth while only consuming 1 mA of supply current per channel. This ac performance is much higher than current competitive CMOS amplifiers. The rail-to-rail output swing and high output drive make these devices a good choice for driving the analog input or reference of analog-to-digital converters. These devices also have low distortion while driving a 600-Ωload for use in telecom systems.
High Slew Rate. . . 10.5 V/µs Typ
High-Gain Bandwidth. . . 5.1 MHz Typ
Supply Voltage Range 2.5 V to 5.5 V
Rail-to-Rail Output
360 µV Input Offset Voltage
Low Distortion Driving 600-Ω 0.005% THD+N
1 mA Supply Current Per Channel
2 pA Input Bias Current
Characterized From TA= −55°C to 125°C
Available in MSOP and SOT-23 Packages
Micropower Shutdown Mode...IDD< 1 µA
Available in Q-Temp Automotive
High Reliability Automotive Applications
Configuration Control / Print Support
Qualification to Automotive Standards
17 nV/√HzInput Noise Voltage
