TL052CPSR

增强型JFET低偏移运算放大器 ENHANCED-JFET LOW-OFFSET OPERATIONAL AMPLIFIERS

description/ordering information

The TL05x series of JFET-input operational amplifiers offers improved dc and ac characteristics over the TL07x and TL08x families of BiFET operational amplifiers. On-chip Zener trimming of offset voltage yields precision grades as low as 1.5 mV TL051A for greater accuracy in dc-coupled applications. Texas Instruments improved BiFET process and optimized designs also yield improved bandwidth and slew rate without increased power consumption. The TL05x devices are pin-compatible with the TL07x and TL08x and can be used to upgrade existing circuits or for optimal performance in new designs.

Direct Upgrades to TL07x and TL08x BiFET Operational Amplifiers

Faster Slew Rate 20 V/µs Typ Without Increased Power Consumption

On-Chip Offset-Voltage Trimming for Improved DC Performance and Precision Grades Are Available 1.5 mV, TL051A
