TSW-103-08-F-S

SAMTEC TSW-103-08-F-S Board-To-Board Connector, 2.54mm, 3Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 3 位置 0.100"（2.54mm）

欧时:
HEADER TH 3POS 2.54MM 1 ROW

得捷:
CONN HEADER VERT 3POS 2.54MM

艾睿:
Look no further than the unshrouded TSW-103-08-F-S header connector from Samtec, a great tool to use when board-to-board interconnects is required. This HDR connector&s;s 3 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. It has a header type gender. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 125 °C. This product is 7.62 mm long, 8.38 mm tall and 2.54 mm deep. TSW-103-08-F-S is housed in black polyester. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 3 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-103-08-F-S  Board-To-Board Connector, 2.54 mm, 3 Contacts, Header, TSW Series, Through Hole, 1 Rows
