TSW-103-22-F-S

SAMTEC TSW-103-22F-S Board-To-Board Connector, 2.54mm, 3Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 3 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 3POS 2.54MM

艾睿:
This unshrouded TSW-103-22-F-S header connector from Samtec is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 3 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product is 7.62 mm long, 8.38 mm tall and 2.54 mm deep. It uses the solder termination method. TSW-103-22-F-S is housed in black polyester. This connector has an operating temperature of -55 to 125 °C.

安富利:
Conn Unshrouded Header HDR 3 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-103-22-F-S  Board-To-Board Connector, 2.54 mm, 3 Contacts, Header, TSW Series, Through Hole, 1 Rows
