TLV2322IDRG4

LinCMOSE低电压低功耗运算放大器 LinCMOSE LOW-VOLTAGE LOW-POWER OPERATIONAL AMPLIFIERS

description

The TLV232x operational amplifiers are in a family of devices that has been specifically designed for use in low-voltage single-supply applications. This amplifier is especially well suited to

ultra-low-power systems that require devices to consume the absolute minimum of supply

currents. Each amplifier is fully functional down to a minimum supply voltage of 2 V, is fully

characterized, tested, and specified at both 3-V and 5-V power supplies. The common-mode input

voltage range includes the negative rail and extends to within 1 V of the positive rail.

Wide Range of Supply Voltages Over Specified Temperature Range:

     TA= –40°C to 85°C...2 V to 8 V

Fully Characterized at 3 V and 5 V

Single-Supply Operation

Common-Mode Input Voltage Range

    Extends Below the Negative Rail and up to VDD –1 V at TA= 25°C

Output Voltage Range Includes Negative Rail

High Input Impedance...1012 Ω Typical

ESD-Protection Circuitry

Designed-In Latch-Up Immunity
