TLV2252AQDRG4

高级LinCMOS轨到轨极低功耗POERATIONAL放大器 Advanced LinCMOS RAIL-TO-RAIL VERY LOW-POWER POERATIONAL AMPLIFIERS

description

The TLV2252 and TLV2254 are dual and quadruple low-voltage operational amplifiers from Texas Instruments. Both devices exhibit rail-to-rail output performance for increased dynamic range in single- or split-supply applications. The TLV225x family consumes only 34 µA of supply current per channel. This micropower operation makes them good choices for battery-powered applications.

Output Swing Includes Both Supply Rails

Low Noise . . . 19 nV/√Hz Typ at f = 1 kHz

Low Input Bias Current . . . 1 pA Typ

Fully Specified for Both Single-Supply and Split-Supply Operation

Very Low Power . . . 34 µA Per Channel Typ

Common-Mode Input Voltage Range Includes Negative Rail

Low Input Offset Voltage

  850 µV Max at TA = 25°C

Wide Supply Voltage Range

  2.7 V to 8 V

Macromodel Included

Available in Q-Temp Automotive

  HighRel Automotive Applications

  Configuration Control / Print Support

  Qualification to Automotive Standards
