TLV4113CDGQR

系列高输出驱动运算放大器，带有关断 FAMILY OF HIGH OUTPUT DRIVE OPERATIONAL AMPLIFIERS WITH SHUTDOWN

description

The TLV411x single supply operational amplifiers provide output currents in excess of 300 mA at 5 V. This enables standard pin-out amplifiers to be used as high current buffers or in coil driver applications. The TLV4110 and TLV4113 come with a shutdown feature.

High Output Drive . . . >300 mA

Rail-To-Rail Output

Unity-Gain Bandwidth . . . 2.7 MHz

Slew Rate . . . 1.5 V/µs

Supply Current . . . 700 µA/Per Channel

Supply Voltage Range . . . 2.5 V to 6 V

Specified Temperature Range:

   − TA = 0°C to 70°C . . . Commercial Grade

   − TA = −40°C to 125°C . . . Industrial Grade

Universal OpAmp EVM
