TLE2084CDWR

神剑高速JFET输入运算放大器 EXCALIBUR HIGH-SPEED JFET-INPUT OPERATIONAL AMPLIFIERS

description

The TLE208x series of JFET-input operational amplifiers more than double the bandwidth and triple the slew rate of the TL07x and TL08x families of BiFET operational amplifiers. The TLE208x also have wider supply-voltage rails, increasing the dynamic-signal range for BiFET circuits to ±19 V. On-chip zener trimming of offset voltage yields precision grades for greater accuracy in dc-coupled applications. The TLE208x are pin-compatible with lower performance BiFET operational amplifiers for ease in improving performance in existing designs.

BiFET operational amplifiers offer the inherently higher input impedance of the JFET-input transistors, without sacrificing the output drive associated with bipolar amplifiers. This makes these amplifiers better suited for interfacing with high-impedance sensors or very low level ac signals. They also feature inherently better ac response than bipolar or CMOS devices having comparable power consumption.

Direct Upgrades to TL05x, TL07x, and  TL08x BiFET Operational Amplifiers

Greater Than 2× Bandwidth 10 MHz and 3× Slew Rate 45 V/µs Than TL08x

On-Chip Offset Voltage Trimming for Improved DC Performance

Wider Supply Rails Increase Dynamic Signal Range to ±19 V
