TLE2064CDG4

TEXAS INSTRUMENTS  TLE2064CDG4  运算放大器, 四路, 2 MHz, 4个放大器, 3.4 V/µs, ± 3.5V 至 ± 18V, SOIC, 14 引脚

The is a quad low-power JFET-input high-output-drive Operational Amplifier doubles the bandwidth of the earlier generation TL06x and TL03x BiFET families without significantly increasing power consumption. Texas Instruments Excalibur process also delivers a lower noise floor than the TL06x and TL03x. On-chip zener trimming of offset voltage yields precision grades for DC-coupled applications. The TL206x device is pin-compatible with other BiFETs, they can be used to double the bandwidth of TL06x circuits. BiFET operational amplifier offer the inherently-higher input impedance of the JFET-input transistors, without sacrificing the output drive associated with bipolar amplifier. This makes them better suited for interfacing with high-impedance sensors or very low-level AC signals. It also features inherently better AC response than bipolar or CMOS devices having comparable power consumption.

.

On-chip offset voltage trimming for improved DC performance

.

Lower noise floor than earlier generations of low-power BiFETs

.

High output drive, specified into 100R loads

.

290µA/channel Typical low supply current

.

6µV/°C Typical offset drift

.

90dB Typical CMRR

.

Green product and no Sb/Br
