THS4131CDGKR

高速，低噪声，全差分I / O放大器 HIGH-SPEED, LOW-NOISE, FULLY-DIFFERENTIAL I/O AMPLIFIERS

DESCRIPON

The THS413x is one in a family of fully-differential input/differential output devices fabricated using Texas Instruments" state-of-the-art BiComI complementary bipolar process. The THS413x is made of a true fully-differential signal path from input to output. This design leads to an excellent common-mode noise rejection and improved total harmonic distortion.

FEATURES

• High Performance

– 150 MHz, –3 dB Bandwidth VCC= ±15 V

– 51 V/µs Slew Rate

– –100 dB Third Harmonic Distortion at 250 kHz

• Low Noise

– 1.3 nV/√Hz Input-Referred Noise

• Differential-Input/Differential-Output

– Balanced Outputs Reject Common-Mode Noise

– Reduced Second-Harmonic Distortion Due to Differential Output

• Wide Power-Supply Range

– VCC= 5 V Single Supply to ±15 V Dual Supply

• ICCSD = 860 µA in Shutdown Mode THS4130

APPLICATIONS

• Single-Ended To Differential Conversion

• Differential ADC Driver

• Differential Antialiasing

• Differential Transmitter And Receiver

• Output Level Shifter
