680- 】 500像素的CCD图像传感器 680-】500-PIXEL CCD IMAGE SENSOR
description
The is a frame-transfer, charge-coupled device CCD image sensor designed for use in single-chip black and white National Television Standards Committee NTSC TV, computer, and special-purpose
applications that require low cost and small size.
High Resolution, 1/3-in Solid-State Image Sensor for NTSC Black and White Applications
340,000 Pixels per Field
Frame Memory
658 H ×496 V Active Elements in Image Sensing Area Compatible With Electronic Centering
Multimode Readout Capability
– Progressive Scan
– Interlaced Scan
– Dual-Line Readout
– Image Area Line Summing
– Smear Subtraction
Fast Single-Pulse Clear Capability
Continuous Electronic Exposure Control From 1/60–1/50,000 s
7.4-µm Square Pixels
Advanced Lateral Overflow Drain Antiblooming
Low Dark Current
High Photoresponse Uniformity
High Dynamic Range
High Sensitivity
High Blue Response
Solid-State Reliability With No Image Burn-In, Residual Imaging, Image Distortion, Image Lag, or
Microphonics
