TSW-108-23-F-S

2.54mm 方针

针座 通孔 8 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 8POS 2.54MM

欧时:
HEADER TH 8POS 2.54MM 1 ROW

立创商城:
2.54mm 方针

艾睿:
As an added safety precaution, the unshrouded TSW-108-23-F-S header connector from Samtec will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This is a 1-row connector. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 20.32 mm long, 8.38 mm tall and 2.54 mm deep. This connector has an operating temperature of -55 to 125 °C. TSW-108-23-F-S is housed in black polyester. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Top Entry Thru-Hole Bag

Newark:
# SAMTEC  TSW-108-23-F-S  Board-To-Board Connector, 2.54 mm, 8 Contacts, Header, TSW Series, Through Hole, 1 Rows
