KEMET T491A336K006AT 表面贴装钽电容, T491系列, 33 µF, ± 10%, 6.3 V, 1206 [3216 公制], A
钽器
得捷:
CAP TANT 33UF 10% 6.3V 1206
立创商城:
33uF ±10% 6.3V
贸泽:
Tantalum Capacitors - Solid SMD 6.3volt 33uF 10%
e络盟:
表面贴装钽电容, 33 µF, 6.3 V, 1206 [3216 公制], T491系列, ± 10%, -55 °C
艾睿:
This T491A336K006AT capacitor from Kemet is made from tantalum solid and has a high capacitance value with a low footprint design. It can withstand a voltage of 6.3 VDC. This solid capacitor has a maximum operating temperature of 125 °C. Its leakage current is 2.1 μA. This product is 3.2 mm long, 1.6 mm tall and 1.6 mm deep. Its capacitance value is 33uF. It has a tolerance of 10%.
安富利:
Cap Tant Solid 33uF 6.3V A CASE 10% 3.2 X 1.6 X 1.6mm SMD 3216-18 2.5 Ohm 125°C T/R
Chip1Stop:
Cap Tant Solid 33uF 6.3V A CASE 10% 3.2 X 1.6 X 1.6mm SMD 3216-18 2.5 Ohm 125 C T/R
TME:
Capacitor: tantalum; 33uF; 6.3VDC; SMD; Case: A; 1206; ±10%
Verical:
Cap Tant Solid 33uF 6.3V A CASE 10% 3.2 X 1.6 X 1.6mm Inward L SMD 3216-18 2.5 Ohm 125C Automotive T/R
Newark:
# KEMET T491A336K006AT Surface Mount Tantalum Capacitor, 33 µF, 6.3 V, T491 Series, ± 10%, 1206 [3216 Metric]
Win Source:
CAP TANT 33UF 10% 6.3V 1206 / 33 µF Molded Tantalum Capacitors 6.3 V 1206 3216 Metric 2.5Ohm
额定电压DC 6.00 V
工作电压 6.3 VDC
电容 33 µF
等效串联电阻ESR 2.5 Ω
容差 ±10 %
产品系列 T491
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 6.3 V
安装方式 Surface Mount
引脚数 2
封装公制 3216-18
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 1.6 mm
封装公制 3216-18
封装 1206
介质材料 Tantalum
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
寿命(小时) 2000h @125℃
制造应用 工业, 车用, Industrial, Portable Devices, 便携式器材, 电源管理, Power Management, Automotive, 消费电子产品, Consumer Electronics
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
T491A336K006AT KEMET Corporation 基美 | 当前型号 | 当前型号 |
T491A336K004AT 基美 | 类似代替 | T491A336K006AT和T491A336K004AT的区别 |
TAJA336K006RNJ 艾维克斯 | 功能相似 | T491A336K006AT和TAJA336K006RNJ的区别 |
T491X157K020AT 基美 | 功能相似 | T491A336K006AT和T491X157K020AT的区别 |
