电容 - 免费, 150毫安,低压差稳压器 Capacitor-Free, 150-mA, Low-Dropout Regulator
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA 4-X2SON(1x1)
得捷:
IC REG LINEAR 3V 150MA 4X2SON
立创商城:
TLV71330PDQNT
德州仪器TI:
150-mA, capacitor-free low-dropout voltage regulator with active output discharge & enable
艾睿:
This LDO TLV71330PDQNT linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.23@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. It only needs a voltage of at least 1.4 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 30mV and line regulation of 5mV. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 3V 0.15A 4-Pin X2SON T/R
Chip1Stop:
LDO Regulator Pos 3V 0.15A 4-Pin X2SON EP T/R
Verical:
LDO Regulator Pos 3V 0.15A 4-Pin X2SON EP T/R
输出接口数 1
输出电压 3 V
输出电流 150 mA
静态电流 50.0 µA
输出电容类型 Ceramic
跌落电压 0.23V @150mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 1.4 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 4
封装 XDFN-4
封装 XDFN-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV71330PDQNT TI 德州仪器 | 当前型号 | 当前型号 |
TLV71330PDQNR 德州仪器 | 完全替代 | TLV71330PDQNT和TLV71330PDQNR的区别 |
