TEXAS INSTRUMENTS TLV1117LV33DCYT 固定电压稳压器, LDO, 2V至5.5V, 455mV压差, 3.3V输出, 1A输出, SOT-223-4
PMIC - 稳压器 - 线性 正 固定 输出 1A SOT-223-4
立创商城:
TLV1117LV33DCYT
得捷:
IC REG LINEAR 3.3V 1A SOT223-4
欧时:
LDO Regulator, TLV1117LV33DCYT
德州仪器TI:
1-A, low-dropout voltage regulator
e络盟:
固定电压稳压器, LDO, 2V至5.5V, 455mV压差, 3.3V输出, 1A输出, SOT-223-4
艾睿:
Control the voltage level of your circuit with this LDO TLV1117LV33DCYT linear regulator from Texas Instruments. It has an overall accuracy of ±1.5 %. This device has a maximum power dissipation of 1590 mW. Its typical dropout voltage at current is 0.09@200mA|0.23@500mA|0.365@800mA|0.455@1A V. This voltage regulation device&s;s single output can produce a current up to 1 A. By only needing an input voltage of 2 V with a maximum of 5.5 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 35mV and line regulation of 5mV. Its maximum power dissipation is 1590 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.7@1A V. Its polarity is positive.
安富利:
LDO Regulator Pos 3.3V 1A 4-Pin3+Tab SOT-223 T/R
Chip1Stop:
LDO Regulator Pos 3.3V 1A 4-Pin3+Tab SOT-223 T/R
TME:
Voltage regulator; LDO, fixed; 3.3V; 1A; SOT223; SMD; Uoper:2÷5.5V
Verical:
LDO Regulator Pos 3.3V 1A 4-Pin3+Tab SOT-223 T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 1A SOT-223-4
输出接口数 1
输出电压 3.3 V
输出电流 1 A
供电电流 100 µA
针脚数 4
耗散功率 1.59 W
静态电流 50.0 µA
输出电容类型 Ceramic
跌落电压 455 mV
调节输出数 1
输入电压Max 5.5 V
输入电压Min 2 V
输出电压Min 3.3 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 1590 mW
精度 ±1.5 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 4
封装 TO-261-4
封装 TO-261-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 消费电子产品, 通信与网络, 计算机和计算机周边, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV1117LV33DCYT TI 德州仪器 | 当前型号 | 当前型号 |
TLV1117LV33DCYR 德州仪器 | 完全替代 | TLV1117LV33DCYT和TLV1117LV33DCYR的区别 |
ADP3339AKCZ-3.3-RL 亚德诺 | 功能相似 | TLV1117LV33DCYT和ADP3339AKCZ-3.3-RL的区别 |
