LDO(低压降)线性电压调节器,双输出,Texas Instruments### LDO(低压降)线性电压调节器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,双输出,Texas Instruments
### LDO(低压降)线性稳压器,Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
欧时:
### LDO(低压降)线性稳压器,双输出,Texas Instruments### LDO(低压降)线性稳压器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LIN 1.8V/3.3V 200MA 6WSON
立创商城:
TLV7111833DDSET
德州仪器TI:
200-mA, high-PSRR, dual-channel low-dropout voltage regulator with enable & active pulldown
e络盟:
LDO稳压器, 固定, 2V至5.5V输入, 2输出: 1.8V/200mA; 3.3V/200mA, 140mVdo, WSON-6
艾睿:
Never worry about components not turning off and on due to lack of voltage with this LDO TLV7111833DDSET linear regulator from Texas Instruments. This device has a maximum power dissipation of 585 mW. Its typical dropout voltage at current is 0.14@200mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s 2 outputs can produce a current up to 0.2 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2 V and no higher than 5.5 V. With a fixed output that has a voltage of 1.8|3.3 V, this is power management at its best. At a load regulation of 15mV and line regulation of 5mV your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 585 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its polarity is positive. The maximum dropout voltage is 0.2@200mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
安富利:
LDO Regulator Pos 1.8V3.3V 0.2A 6-Pin WSON T/R
Chip1Stop:
LDO Regulator Pos 1.8V3.3V 0.2A 6-Pin WSON T/R
Verical:
LDO Regulator Pos 1.8V3.3V 0.2A 6-Pin WSON T/R
DeviceMart:
IC REG LDO 1.8V/3.3V .2A 6WSON
输出接口数 2
输出电流 200 mA
供电电流 110 µA
针脚数 6
耗散功率 0.585 W
静态电流 35 µA
输出电容类型 Ceramic
跌落电压 140 mV
调节输出数 2
输入电压Max 5.5 V
输入电压Min 2 V
输出电流Max 200 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 585 mW
精度 ±2 %
输入电压 2V ~ 5.5V
安装方式 Surface Mount
引脚数 6
封装 WFDFN-6
长度 1.55 mm
宽度 1.55 mm
高度 0.75 mm
封装 WFDFN-6
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV7111833DDSET TI 德州仪器 | 当前型号 | 当前型号 |
TLV7111833DDSER 德州仪器 | 功能相似 | TLV7111833DDSET和TLV7111833DDSER的区别 |
