TC1015-2.85VCT713

TC1015 低压降电压调节器### LDO（低压降）线性电压调节器，Microchip

电路数量Number of Regulators| 1 \---|--- 输入电压VINVoltage - Input| 6.5V 输出电压VOUTVoltage - Output| 2.85V 输出电流IoCurrent - Output| 150mA/0.15A 最大压降VDOVoltage - Dropout| 270mV/0.27V 带使能脚EN/CEON/OFF功能With Enable Pin| 无 No 最大耗散功率PdPower dissipation| Description & Applications| 50 mA, 100 mA and 150 mA CMOS LDO •Low Supply Current 50 µA, typical • Low Dropout Voltage • High Output Voltage Accuracy • Standard or Custom Output Voltages • Power-Saving Shutdown Mode • Reference Bypass Input for Ultra Low-Noise Operation • Overcurrent and Overtemperature Protection • Space-Saving 5-Pin SOT-23 Package • Pin-Compatible Upgrades for Bipolar Regulators • Battery-Operated Systems • Portable Computers • Medical Instruments • Instrumentation • Cellular/GSM/PHS Phones • Linear Post-Regulator for SMPS • Pagers 描述与应用| 50毫安，100毫安和150毫安的CMOS LDO •低电源电流（50μA，典型值） •低压差 •输出电压精度高 •标准或定制输出电压 •省电关断模式 •超低噪音运行的参考旁路输入 •过流和过热保护 •节省空间的5引脚SOT-23封装 •双极型稳压器引脚兼容的升级 •电池供电系统 •便携式电脑 •医疗器械 •仪表 •蜂窝式/ GSM/ PHS电话 •线性后稳压SMPS •寻呼机
