TC2015-2.8VCTTR

50毫安100毫安， 150毫安CMOS LDO的 50 mA, 100 mA, 150 mA CMOS LDOs

PMIC - 稳压器 - 线性 输出 100mA SOT-23-5

得捷:
IC REG LINEAR 2.8V 100MA SOT23-5

立创商城:
TC2015-2.8VCTTR

艾睿:
Stable power is ideal for better processing this LDO TC2015-2.8VCTTR linear regulator developed by Microchip Technology will help do so. It has an overall accuracy of ±0.4 %. Its typical dropout voltage at current is 0.09@100mA V. This device has a maximum power dissipation of 318 mW. This voltage regulation device&s;s single output can produce a current up to 0.1 A. This will operate at a minimum voltage of 2.7 V and a maximum voltage of 6 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2.8 V, this is power management at its best. Using a load regulation of 0.33%Typ and line regulation of 0.05%Typ is needed for a programmable DC power supply. Its maximum power dissipation is 318 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.14@100mA V.

Allied Electronics:
100mA LDO with Shutdown & V REF Bypass, TC1015 upgrade

安富利:
LDO Regulator Pos 2.8V 0.1A 5-Pin SOT-23A T/R

Chip1Stop:
LDO Regulator Pos 2.8V 0.1A Automotive 5-Pin SOT-23A T/R
