LDO(低压降)线性稳压器,最大 100mA,1.0V 至 2.9V,Texas Instruments### LDO(低压降)线性稳压器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO(低压降)线性稳压器,最大 100mA,1.0V 至 2.9V,Texas Instruments
得捷:
IC REG LINEAR 1.8V 50MA SC70-5
立创商城:
TPS71518DCKR
德州仪器TI:
50-mA, 24-V, ultra-low-IQ, low-dropout LDO voltage regulator
欧时:
### LDO(低压降)线性稳压器,最大 100mA,1.0V 至 2.9V,Texas Instruments### LDO(低压降)线性稳压器,Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
e络盟:
TEXAS INSTRUMENTS TPS71518DCKR 固定电压稳压器, LDO, 3V至24V, 415mV压差, 1.8V输出, 50mA输出, SC-70-5
艾睿:
Having trouble maintaining a steady voltage? This LDO TPS71518DCKR linear regulator from Texas Instruments will give you control over the voltage levels of your circuit. Its typical dropout voltage at current is 0.415@50mA V. This device has a maximum power dissipation of 320 mW. It has an overall accuracy of ±4 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. Using the part will provide the power your application needs by requiring a voltage only of 2.5 V and not exceeding a voltage of 24 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 22mVTyp and line regulation of 20mVTyp. Its maximum power dissipation is 320 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its polarity is positive. The maximum dropout voltage is 0.75@50mA V. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.
安富利:
LDO Regulator Pos 1.8V 0.05A 5-Pin SC-70 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 50mA, Fixed1.8V, High Input Voltage, Low Quiescent Current LDO Regulator Pos 1.8V 0.05A 5-Pin SC-70 T/R
Verical:
LDO Regulator Pos 1.8V 0.05A 5-Pin SC-70 T/R
Newark:
# TEXAS INSTRUMENTS TPS71518DCKR Fixed LDO Voltage Regulator, 3V to 24V, 415mV Dropout, 1.8Vout, 50mAout, SC-70-5
DeviceMart:
IC REG LDO 1.8V 50MA SC70-5
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 50mA SC-70-5
额定功率 0.32 W
输出接口数 1
输入电压DC 24.0V max
输出电压 1.8 V
输出电流 50 mA
针脚数 5
耗散功率 0.32 W
静态电流 0.0032 mA
输出电容类型 Ceramic
跌落电压 415 mV
调节输出数 1
输入电压Max 24 V
输入电压Min 2.5 V
输出电压Min 1.8 V
输出电流Max 50 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 320 mW
精度 4 %
输入电压 2.5V ~ 24V
安装方式 Surface Mount
引脚数 5
封装 SC-70-5
长度 2 mm
宽度 1.25 mm
高度 0.9 mm
封装 SC-70-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS71518DCKR TI 德州仪器 | 当前型号 | 当前型号 |
TPS71518DCKRG4 德州仪器 | 类似代替 | TPS71518DCKR和TPS71518DCKRG4的区别 |
