TC2185-3.0VCTTR

50毫安100毫安， 150毫安CMOS LDO的 50 mA, 100 mA, 150 mA CMOS LDOs

PMIC - 稳压器 - 线性 正 固定 输出 150mA SOT-23-5

得捷:
IC REG LINEAR 3V 150MA SOT23-5

立创商城:
TC2185-3.0VCTTR

艾睿:
Use the LDO TC2185-3.0VCTTR linear regulator from Microchip Technology to maintain a constant output voltage. It has an overall accuracy of ±0.4 %. This device has a maximum power dissipation of 318 mW. Its typical dropout voltage at current is 0.09@100mA|0.14@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.7 V that does not exceed 6 V. With a fixed output that has a voltage of 3 V, this is power management at its best. A load regulation of 0.43%Typ and line regulation of 0.05%Typ is necessary for providing a constant voltage level at your output. Its maximum power dissipation is 318 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. The maximum dropout voltage is 0.14@100mA|0.21@150mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.

Allied Electronics:
150mA LDO w/ Shutdown & V REF BYPASS, TC1185 upgrade5 SOT-23 T/R

安富利:
LDO Regulator Pos 3V 0.15A 5-Pin SOT-23A T/R

Chip1Stop:
LDO Regulator Pos 3V 0.15A 5-Pin SOT-23A T/R

Verical:
LDO Regulator Pos 3V 0.15A Automotive 5-Pin SOT-23A T/R
