低压差稳压器
PMIC - 稳压器 - 线性 正 固定 1 输出 200mA 4-DSLGA
得捷:
IC REG LINEAR 1.8V 200MA 4DSLGA
立创商城:
TLV70518YFMR
德州仪器TI:
200-mA, high-PSRR, low-IQ, low-dropout voltage regulator with low-noise & enable
贸泽:
低压差稳压器
艾睿:
Are you not sure what voltages you exactly need? No problem implement this TLV70518YFMR linear regulator by Texas Instruments in order to play around with the voltages. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment.
Verical:
IC REG LDO 1.8V 0.2A 4DSLGA
输出接口数 1
输出电压 1.8 V
输出电流 200 mA
供电电流 55µA ~ 315µA
静态电流 30.0 µA
输出电容类型 Ceramic
跌落电压 0.145V @200mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 2 V
输出电压Min 1.8 V
输出电流Max 0.2 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 5.5 V
安装方式 Surface Mount
引脚数 4
封装 XFLGA-4
长度 0.77 mm
宽度 0.77 mm
高度 0.145 mm
封装 XFLGA-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TLV70518YFMR TI 德州仪器 | 当前型号 | 当前型号 |
TLV70518YFMT 德州仪器 | 完全替代 | TLV70518YFMR和TLV70518YFMT的区别 |
