TLV117118DCYT

TEXAS INSTRUMENTS  TLV117118DCYT  固定电压稳压器, LDO, 2V至5.5V, 570mV压差, 1.8V输出, 1A输出, SOT-223-3

LDO（低压降）线性稳压器，1A，TLV11 系列，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

得捷:
IC REG LINEAR 1.8V 1A SOT223-4

立创商城:
TLV117118DCYT

德州仪器TI:
1-A, low-dropout voltage regulator tab GND

欧时:
### LDO（低压降）线性稳压器，1A，TLV11 系列，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

e络盟:
固定电压稳压器, LDO, 2V至5.5V, 570mV压差, 1.8V输出, 1A输出, SOT-223-3

艾睿:
Use the LDO TLV117118DCYT linear regulator from Texas Instruments to maintain a constant output voltage. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.115@200mA|0.285@500mA|0.455@800mA|0.57@1A V. This voltage regulation device&s;s single output can produce a current up to 1 A. This will operate at a minimum voltage of 2 V and a maximum voltage of 5.5 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 35mV and line regulation of 5mV. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. The maximum dropout voltage is 0.8@1A V. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.

安富利:
LDO Regulator Pos 1.8V 1A 4-Pin3+Tab SOT-223 T/R

Chip1Stop:
LDO Regulator Pos 1.8V 1A 4-Pin3+Tab SOT-223 T/R

Verical:
LDO Regulator Pos 1.8V 1A 4-Pin3+Tab SOT-223 T/R

Newark:
# TEXAS INSTRUMENTS  TLV117118DCYT  Fixed LDO Voltage Regulator, 2V to 5.5V, 570mV Dropout, 1.8Vout, 1Aout, SOT-223-3
