TCJW157M006R0070

AVX  TCJW157M006R0070.  钽电容, 150uF 6.3V, 0.07Ω, 2312

TCJ 系列

片式钽器，带电导的聚合物电极

与传统的二氧化锰电极电容器相比，ESR 更低、非点火故障模式更安全、电容值保留性能更佳

外壳尺寸小，非常适用于手机、PDA 和其他便携式电子设备

适合工作温度高达 125°C 的电源管理系统

欧时:
### TCJ 系列片式钽电容器，带电导的聚合物电极 与传统的二氧化锰电极电容器相比，ESR 更低、非点火故障模式更安全、电容值保留性能更佳 外壳尺寸小，非常适用于手机、PDA 和其他便携式电子设备 适合工作温度高达 125°C 的电源管理系统 尺寸 mm --- 外壳代码 | EIA 代码 | L ±0.2 | W +0.2 -0.1 | H +0.2 -0.1 | W1 ±0.2 | A +0.3-0.2 A | 1205 | 3.2 | 1.6 | 1.6 | 1.2 | 0.8 B | 1210 | 3.5 | 2.8 | 1.9 | 2.2 | 0.8 C | 2312 | 6 | 3.2 | 2.6 | 2.2 | 1.3 G | 1206 | 3.2 | 1.6 | 1.5 | 1.2 | 0.8 H | 1210 | 3.5 | 2.8 | 1.5 | 2.2 | 0.8 K | 1206 | 3.2 | 1.6 | 1 | 1.2 | 0.8 P | 0805 | 2.05 | 1.35 | 1.5 | 1 | 0.5 R | 0805 | 2.05 | 1.3 | 1.2 | 1 | 0.5 T | 1210 | 3.5 | 2.8 | 1.2 | 2.2 | 0.8 W | 2312 | 6 | 3.2 | 1.5 | 2.2 | 1.3 ![http://china.rs-online.com/largeimages/L405941-01.gif]http://china.rs-online.com/largeimages/L405941-01.gif ### SMT 125°C

贸泽:
钽质电容器-SMD聚合物 6.3V 150uF 20% 2312 ESR=70mOhm

e络盟:
钽电容, 150uF 6.3V, 0.07Ω, 2312

艾睿:
This TCJW157M006R0070 polymer electrolyte from AVX is a high performing capacitor. It can withstand a voltage of 6.3 VDC. It has 2 terminals. Its leakage current is 90 μA. Its capacitance value is 150uF. This polymer electrolyte has a minimum operating temperature of -55 °C and a maximum of 125 °C. This product is 6 mm long, 1.5Max mm tall and 3.2 mm deep.

Allied Electronics:
150uF SMD Solid Polymer Tantalum Electrolytic Capacitor, 6.3VDC +/-20%, TCJ Series

安富利:
Cap Tant Solid 150uF 6.3V W CASE 20% 6 X 3.2 X 1.5mm SMD 6032-15 0.07 Ohm 125°C T/R

Chip1Stop:
Cap Tant Solid 150uF 6.3V W CASE 20% 6 X 3.2 X 1.5mm SMD 6032-15 0.07 Ohm 125 C T/R

TME:
Capacitor: tantalum-polymer; 150uF; 6.3VDC; Case: W; 2312; ESR:70mΩ

Verical:
Cap Tant Polymer 150uF 6.3VDC W CASE 20% 6 X 3.2 X 1.5mm SMD 6032-15 0.07 Ohm 105C T/R

Newark:
# AVX  TCJW157M006R0070  Surface Mount Tantalum Capacitor, 150 µF, 6.3 V, TCJ Series, 2312 [6032 Metric], -55 °C
