TLV7163318PDPQT

电容 - 免费，双通道， 150毫安，低压差稳压器（ LDO ）的1,2-毫米1,2毫米SON封装 Capacitor-Free, Dual, 150-mA, Low-Dropout Voltage Regulator LDO in 1,2-mm 1,2-mm SON Package

PMIC - 稳压器 - 线性 正 固定 输出 150mA 6-X2SON（1.2x1.2）

得捷:
IC REG LIN 3.3/1.8V 150MA 6X2SON

立创商城:
TLV7163318PDPQT

德州仪器TI:
150-mA, dual-channel low-dropout voltage regulator with enable

贸泽:
低压差稳压器 Dual CH Capless 150mA LDO

艾睿:
Use this LDO TLV7163318PDPQT linear regulator from Texas Instruments to vary your voltage levels to your desired level. Its typical dropout voltage at current is 0.21@150mA|0.35@150mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s 2 outputs can produce a current up to 0.15Min|0.15Min A. By only needing an input voltage of 1.4 V with a maximum of 5.5 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 1.8|3.3 V, this is power management at its best. Users like the load regulation of 0.07mV/mATyp and line regulation of 0.02%/VTyp. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.42@150mA|0.575@150mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 3.3V/1.8V 0.15A 6-Pin X2SON T/R

Verical:
LDO Regulator Pos 1.8V3.3V 0.15A/0.15A 6-Pin X2SON EP T/R
