TLV7162818PDPQT

电容 - 免费，双通道， 150毫安，低压差稳压器（ LDO ）的1,2-毫米1,2毫米SON封装 Capacitor-Free, Dual, 150-mA, Low-Dropout Voltage Regulator LDO in 1,2-mm 1,2-mm SON Package

PMIC - 稳压器 - 线性 正 固定 输出 150mA 6-X2SON（1.2x1.2）

得捷:
IC REG LDO 2.8V/1.8V 0.15A 6XSON

立创商城:
TLV7162818PDPQT

德州仪器TI:
150-mA, dual-channel low-dropout voltage regulator with enable

贸泽:
LDO Voltage Regulators Dual CH Capless 150mA LDO

艾睿:
Keep the energy stable for every system by using this LDO TLV7162818PDPQT linear regulator by Texas Instruments. Its typical dropout voltage at current is 0.23@150mA|0.35@150mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s 2 outputs can produce a current up to 0.15Min|0.15Min A. With a small input voltage of 1.4 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.8|2.8 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.07mV/mATyp and line regulation of 0.02%/VTyp. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.45@150mA|0.575@150mA V. Its polarity is positive.

Verical:
LDO Regulator Pos 1.8V2.8V 0.15A/0.15A 6-Pin X2SON EP T/R
